EXTERIOR
Projector-beam headlamps with auto on/off feature and Daytime Running Lights (DRL) with
manual on/off feature
Hybrid Synergy Drive® blue accent headlamps
Integrated front fog lamps
LED (light-emitting diode) for tail, stop and side marker lamps
16-in. steel wheels with full wheel covers and P215/60R16 tires
Heated outside mirrors
Acoustic noise-reducing front windshield
High Solar Energy-Absorbing (HSEA) glass
Washer-linked variable intermittent windshield wipers
Power tilt/slide moonroof
Rear window defogger with timer
Chrome-tipped exhaust
INTERIOR
Multi-Information Display with Eco Drive Level, energy monitor, outside temperature, average fuel economy,
distance to empty, average speed and trip distance
Remote keyless entry system with lock, unlock, trunk-release, panic and remote illuminated entry function
Smart Key System24 on two doors and trunk with Push Button Start
Tilt/telescopic adjustable steering wheel with audio and climate controls
Cruise control
4-spoke leather-wrapped steering wheel and wood-grain-style shift knob
Leather-trimmed seats and door trim with integrated armrests, sliding center armrest, power front
passenger seat and wood-grain-style interior trim
Heated front seats
Multi-adjustable power driver’s seat with adjustable headrest, seatback pocket and lumbar support
60/40 split fold-down rear seat with security locks, adjustable headrests and seatbelt positioning clips
Dual zone CFC-free automatic climate control with electric compressor, dust and pollen filter,
Plasmacluster™27 ionizer and rear-seat vents
Voice-activated touch-screen DVD navigation system30 with integrated backup camera,31 JBL® AM/FM
4-disc CD changer with MP3/WMA playback capability, eight speakers, XM® Radio11 with XM NavTraffic®30, auxiliary audio jack, USB28 port with iPod® connectivity, and hands-free
phone capability and music streaming via Bluetooth®29 wireless technology
Day/night rearview mirror
Auto-dimming rearview mirror with compass
Illuminated entry
HomeLink® universal transceiver
Power windows with auto up/down, jam protection in all positions and retained-power features
Power door locks with shift-activated locking feature and anti-lockout feature
Optitron meters with speedometer, instantaneous fuel economy meter, digital odometer, twin tripmeters
with outside temperature, engine coolant and fuel gauges, and instant fuel consumption
Rear-seat reading lights
Foot pedal parking brake
Remote hood, trunk and fuel-filler door releases
Dual sun visors with illuminated vanity mirrors
Overhead console with maplights and sunglasses holder
Lockable illuminated glove compartment
Digital quartz clock
Bi-level covered center console with storage
Sliding center armrest
Two 12V auxiliary power outlets
Front cup holders
Fold-down rear center armrest with dual cup holders
Trunk-mounted cargo net
SAFETY AND CONVENIENCE
Star Safety SystemTM with Vehicle Dynamics Integrated Management (VDIM)40 —
includes Vehicle Stability Control (VSC)17 + Traction Control (TRAC),
Anti-lock Brake System (ABS) with Electronic Brake-force Distribution (EBD)
and Brake Assist16
Smart Stop Technology34
Driver and front passenger Advanced Airbag System35
Driver and front passenger front seat-mounted side airbags and front and rear side curtain airbags35
Driver’s knee airbag35
3-point seatbelts for all seating positions, driver-side Emergency Locking Retractor (ELR) and
Automatic/Emergency Locking Retractors (ALR/ELR) on all passenger belts
Outboard rear seatbelt comfort guides
Front and rear crumple zones
Side-impact door beams
Direct Tire Pressure Monitor System (TPMS)36
Energy-absorbing collapsible steering column
Child-protector rear door locks
LATCH (Lower Anchors and Tethers for Children) for outboard rear seating positions only
Internal trunk-release handle
Battery-saver feature — deactivates dome light after 20 minutes
Engine immobilizer37
MECHANICAL/PERFORMANCE
Hybrid System Net Power 187 hp (140 kW)
Gasoline Engine 2.4-liter 4-cylinder Hybrid DOHC 16-valve VVT-i;
147 hp @ 6000 rpm; 138 lb.-ft. @ 4400 rpm
Ignition Electronic, with Toyota Direct Ignition (TDI)
Electric Motor
Power output 199 lb.-ft. @ 0–1500 rpm (105 kW @ 4500 rpm)
Motor type Permanent magnet AC synchronous motor
Voltage 650V maximum
Traction Battery
Power output 40 hp (30 kW)
Type Sealed Nickel-Metal Hydride (Ni-MH)41
Voltage 244.8V
Transmission Electronically Controlled continuously Variable Transmission (ECVT)
Suspension MacPherson strut front suspension with gas-filled shock absorbers
and stabilizer bar; dual-link independent MacPherson strut rear
suspension with gas-filled shock absorbers and stabilizer bar
Steering Electric Power Steering (EPS); rack-and-pinion with
electric power-assist
Turning circle diameter, curb to curb (ft.) 36.1
Brakes Power-assisted ventilated front/solid rear discs with
integrated regenerative braking
EXTERIOR DIMENSIONS (in.)
Overall height, unloaded 57.5
Overall width/length 71.7/189.2
Wheelbase 109.3
Ground clearance 5.9
Track (front/rear) 62.0/61.6
Coefficient of drag (Cd) 0.27
INTERIOR DIMENSIONS front/rear (in.)
Head room
without moonroof (with moonroof) 38.8/37.8 (37.9/37.4)
Shoulder room 57.8/56.7
Hip room 54.6/53.9
Leg room 41.6/38.3
Seating capacity 5
WEIGHTS AND CAPACITIES
Curb weight (lb.) 3680
EPA passenger volume (cu. ft.) 101.4
Luggage capacity, rear seat up (cu. ft.) 10.6
Fuel tank (gal.) 17.2
TIRES
Size P215/60R16
Type: All-Season Michelin CrossClimate
